chainflex® cables & hoses for cleanroom applications
Having abrasion-resistant cables that meet cleanroom standards are essential in semi-conduction manufacturing, since the ISO norm 14644-1 comes into effect. ISO norm 14644-1 categorizes how many particles of <3µm are allowed to be contained in 1m3air into 9 different classes. These particles can damage the product that will be manufactured, increasing the scrap rate, so ensuring that all equipment being used with a clearoom is resistant to abraions is key.
Cleanrooms are not only found in semiconductor manufacturing, but also in laboratories, medical technology and the pharmaceutical industry—wherever meticulous cleanliness is essential. As our quality demand keeps increasing, the demand for this kind of production is also growing. Just think about how many cables are involved within the production of large flat-screen TVs, where any pixel errors are unacceptable. The same applies to vaccine cannulas, which have to be produced with precision and under hygienic conditions. If moving parts such as cable carriers are installed with flexible cables running inside, they have to be set up in a manner that reduces abrasion to minimal amounts, or the particles that develop during manufacturing, or emitted by the outside, have to be removed from the ambient air, which can be extremely costly. By using cables with low abrasion, i.e. few particles, the cumbersome and expensive removal of air particles is no longer necessary.
Range of cables for cleanrooms – CFCLEAN
The CFCLEAN.EVO: The evolution for the cleanroom
400 million cycles for pick and place machine
The company Assembléon Netherlands B.V. has developed a new generation of fully automatic pick and place machines of the series iFlex T4, T2 and H1 with vision system. They can be used for low and high volumes.
The SMD assembly is carried out by robots on one or both sides in serial quality for components from a size of 0402. The part handling is between 51,000 (T4) and 12,000 (H1) per hour.
The acceleration and the speed are on the one hand 35m/s2 (y-axis) and 20m/s2 (x-axis), and on the other hand 2m/s and 1.5m/s. Required service life of the respective components is 400 million cycles, which corresponds to approximately seven years of continuous operation.
This is the e-skin® flat
e-skin® flat and CFCLEAN - together they revolutionise your overall plant effectiveness, generate higher production line yields, and they are modular and conserve resources.
Further igus products suitable for cleanroom use
Energy chain series E6.1
With the E6.1, a new generation enters the cleanroom. The considerably simplified handling and improved accessibility to the interior and the reduced weight make assembly much easier. Our E6.1 naturally has our highly flexible cables in its luggage, which, with their abrasion-resistant outer jacket, are ideal for cleanroom applications.
Cables for use in dry cleanrooms
A dry cleanroom is a specially controlled environment characterized by extremely low humidity and a high level of particle-free air. A classic example of a dry cleanroom is battery production.
The IPA certificates issued by the Fraunhofer Institute are regarded as an important standard for the cables used here.
All halogen-free chainflex cables with a TPE outer jacket meet the requirements of ISO Classes 4 and 5 and offer impressive benefits in terms of minimal particle abrasion, efficiency and safety.
