drylin® T linear guide carriages

Dimensionally identical to standard commercial linear carriages with recirculating ball bearing guides
drylin® T guide carriages offer a low cost, maintenance-free alternative to recirculating ball bearings. Both are dimensionally identical, allowing for easy one-to-one replacement. drylin® T guide carriages are also made using igus’® self-lubricating plastic polymers to ensure long-term, high quality performance while saving time and money on maintenance. The robust rail guide even guarantees a service life of up to 50,000km. Additionally, miniature rails and guides are available for applications requiring small installation spaces.

drylin® T linear carriage with automatic clearance adjustment

Heavy-Duty Standard Carriage with Adjustable Clearance

  • 50% longer service life through iglide J200 slider
  • Robust captive bearing system
  • Adjustable bearing clearance
Browse the Shop
drylin® T standard linear carriage

Standard Carriage

  • Preset bearing clearance
  • Manual bearing alignment
  • With manual clamp (optional)
Browse the Shop
drylin® T guide carriage with automatic adjustment of the bearing clearance

Standard Carriage with Automatic Clearance Reduction

  • Automatic clearance adjustment
  • Different installation sizes
  • Easy installation
Browse the Shop

Why choose drylin® T rail guides?

One-to-one replacement easily

Robust

Connector and hole dimensions identical to conventional recirculating ball bearing systems

Precise carriage guidance

Property icon

from 0.02 - 0.15 mm
optional clearance adjustment:

Property icon

Self-lubricating and maintenance-free
The fact that no lubrication is necessary means less maintenance and lower costs for you.

Customer Applications

drylin® T in welding technology

Long service life and low costs
The drylin® TK-01-15 linear guide is not only dirt resistant. It is also extremely robust and guarantees a long service life even under extreme environmental conditions.

drylin® T linear rail in welding rod for automotive industry

drylin® T in label feeding system

GESET ETIKETTIER-SYSTEME GmbH relies on drylin® T
Rapid and flexible format adjustment, absolutely self-lubricating and competitively priced – drylin® T linear guide system is the solution for such exacting standards. One further benefit is that the guide carriage is also available with a manual clamp.

drylin® T rail guide in label feed system for packaging machine

drylin® T in a grinding machine

Adjustments in linear movements in cupboards, doors and more
The pressing roller in a grinding machine and the imbalance of the grinding tools are guided over a drylin® T rail in this machine from SMB MASCHINENBAU GmbH. The vibration-dampening properties of the plastic bearings provide support for the elaborate grinding process.

drylin® T in a grinding machine

drylin® T in an enveloping machine

4 double strokes per second – with little clearance and maintenance-free
drylin® T rail guides are used in this enveloping machine to guide an envelope suction opener that is mounted on one side. In this application, a variable stroke of 4mm to 10mm and a cycle output of 4 double strokes per second takes place. The guidance must be clearance and maintenance-free and may not require lubrication.

drylin® T rail with measuring system for tools

Measuring system saves a lot of time and money
Tool changing time is reduced considerably by the measuring system from the drylin®  T product range. The drilling and cutting tools in CNC processing machines are measured prior to processing and the values are entered in the computer. This means that every tool needs to be measured only once. The gauge is guided on a drylin® T rail.

drylin® T clamps for linear rail guidance

Manual clamps for an easy positioning with plastic clamp element or with brass bottom clamps for different installation sizes of the drylin® T Series.

Benefits:

  • Compact or heavy-duty design
  • Available for sizes 15mm-30mm
  • Holding force up to 500N
Browse the Shop

drylin® T miniature guide for small installation spaces

Linear rails with a compact design in 4 installation sizes
The dimensions of the miniature linear rails from the drylin® T product range are identical to most commercially available miniature recirculating ball bearing systems. The compact design makes the system of miniature guides especially suitable for small installation spaces. The simple and effective rail guide is tough and cost-effective.

With the TWE-04, igus® provides a guide carriage with adjustable bearing clearance for miniature guides.

Browse the Shop
