Cable quality monitoring CF.Q

Avoid unplanned system downtime due to cable failures

The isense CF.Q module is used for the early detection of the change in electrical specifications of chainflex® cables due to the mechanical loads during operation in an igus® e-chain system®. For this purpose, the electrical resistance of a dedicated conductor loop is measured during operation. Temperature-related resistance changes are compensated for by means of PT100 measurement at the installation location of the cable. Microprocessor-based, continuous data evaluation is carried out by own algorithms of igus®. These form arithmetic as well as sliding average values of the measured resistance values approx. 50 times per second and evaluate them in a temporal context.
If the system detects a permanent change in the electrical specifications, it recommends replacing the cable as soon as possible by switching a potential-free contact. If the cable is not replaced, the system switches off the system as a precaution in the event of a complete core rupture. For later investigations, the system logs all measured values that led to the warning and shutdown.

Advantages of CF.Q:

  • Avoid unplanned system downtime due to cable failures when using chainflex® cables outside the chainflex® guarantee conditions!
  • Detect mechanical stress of chainflex® cables under extreme operating conditions at an early stage.
  • Plan maintenance work cost-effectively in advance
Request CF.Q
Smart plastics sensors

Two options to integrate CF.Q

Option 1 - sacrificial cable
In this option, space is still needed to route an additional cable in the e-chain® because the CF.Q is routed as a "sacrificial cable" in the e-chain®. All cores of the cable are "connected in series" and connected to the measuring input of the module
  • Advantage: All cores are measured, which means that there is no need to select the most frequently used cores.
  • Disadvantage: Regardless of the production batch and the assembly method, even cables from the same production batch can achieve different service life durations.
Option 2 - unused cores of a cable
In a monitored cable, two unused cores are defined as measuring cores and, if necessary, routed to the measuring connections of the CF.Q A module by means of a shielded extension cable. This often requires a modification of the connector assembly, as the two cores must be led out of the connector on the distributor side at the cable entry.
  • Advantage: The cable actually used by the customer is monitored
  • Disadvantage: The original cable often has to be replaced by a variant with two additional cores, which usually increases the cable diameter, and the apparently "weakest" cores should be chosen.

A practical example

  • Application: Bread wrapping machine
  • What was required: smart energy supply system
  • Requirements: Preventive cable monitoring
  • Product: CF.Q DIN rail module
  • Field of application: Automation of any kind
  • Success for the customer: The company GHD Georg Hartmann Maschinenbau was looking for a reliable energy supply system for one of its automatic packaging machines, including preventive monitoring to avoid machine failures
Go to the application report
Bread wrapping with CF.Q

Smart plastics industry 4.0 solutions, tools and applications

cranes

Reliable condition monitoring in the crane industry

Heavy loads, long periods of use, and a wide variety of weather conditions – cranes must present a fantastic performance. To ensure this at all times, reliable condition monitoring concepts are needed.
Learn More
smart plastics automotive

Predictive maintenance in automotive production

In automotive production, the assembly lines never stand still. Smart production concepts in the style of predictive maintenance have long been established in these production lines.
Learn More
smart plastics dashboard
Push/pull force in the online dashboard
i.Cee dashboard
e-chain speed via the dashboard

Application examples with smart plastics

smart examples with e-chain®, chainflex® cables and bearings.

Smart e-chain® and cables

Smart Plastics e-chain® and cables

Use smart plastics to stay abreast of how your chain is doing.

Our intelligent e-chain® systems are already reliably in use in hundreds of thousands of applications worldwide - from beverage machines and CNC machines to steel mills.
Learn More

Smart bearing technology

Smart plain bearings

Don't let a defective plain bearing ruin your day.

Smart plain bearings are great for sensitive or hard-to-reach spots on a machine, since they allow the bearing's condition to be assessed at any time.

Learn More

Smart Applications

Smart applications

Customer application examples with smart plastics

Whether a new project for Industry 4.0 or efficiency-driven retrofitting - our smart plastics solutions are available as universal modular systems and can be individually adapted to any system.
Learn More

Download the smart plastics brochure

Smart Plastics Brochure
Download Brochure

Contact a smart e-chain® expert

Contact Scott Parker, energy chain expert
Contact an expert now
