Fully-enclosed triflex® for 2D and 3D movements

332-16

Inner height hi: 16 mm
Inner width Bi: 16 mm
Bending radii R: 38 - 100 mm
Pitch: 13.3 mm

332-32

Inner height hi: 32 mm
Inner width Bi: 32 mm
Bending radii R: 75 - 250 mm
Pitch: 25 mm

332-50

Inner height hi: 50 mm
Inner width Bi: 50 mm
Bending radii R: 100 - 250 mm
Pitch: 30 mm

332-75

Inner height hi: 75 mm
Inner width Bi: 75 mm
Bending radii R: 140 - 300 mm
Pitch: 36 mm

352-50

Inner height hi: 50 mm
Inner width Bi: 50 mm
Bending radii R: 10 - 250 mm
Pitch: 30 mm

333-16

Inner height hi: 16 mm
Inner width Bi: 16 mm
Bending radii R: 38 - 100 mm
Pitch: 13.3 mm

333-32

Inner height hi: 32 mm
Inner width Bi: 32 mm
Bending radii R: 75 - 250 mm
Pitch: 25 mm

333-50

Inner height hi: 50 mm
Inner width Bi: 50 mm
Bending radii R: 100 - 250 mm
Pitch: 30 mm

333-75

Inner height hi: 75 mm
Inner width Bi: 75 mm
Bending radii R: 140 - 300 mm
Pitch: 36 mm

353-50

Inner height hi: 50 mm
Inner width Bi: 50 mm
Bending radii R: 10 - 250 mm
Pitch: 30 mm

This modular, rugged joint system is suitable for:

• Three-axis movements for machines of any type
• For dirt-filled environments
• High tensile strength
• Where rectangular shapes are requested
• Completely closed - reliable protection against dirt and chips
• Combination of different bending radii and axes
• Connection and separation possible at any chain
• Flanged mounting brackets or brackets, galvanized steel
• Snap-open Series 352 and 353
• Combination of Series 353/333 possible

Typical industrial sectors and applications

• Machine tools
• Robotics
• Material handling system
• Plastics industry
• Construction machinery
• Vehicle manufacturing
• Medical equipment

Application examples

Applications in various industrial sectors and in the igus® test laboratory.
