chainflex® fibre optic cable CFLG.LB.PUR

Discontinued Model

1 of 3

Requirements: Gradient glass-fiber cable for heaviest duty applications
Download Data Sheet
Outer jacket: TPE
Halogen-free
Silicone-free
Oil resistance: Oil-resistant according to DIN EN 60811-404, resistant to organic oils according to VDMA 24568 with Plantocut 8 S-MB by DEA
UV-resistant
PVC-free
chainflex® class: 7.5.4.1

Item no.

CFLG.2LB.PUR.50/125

formerly: CFLG-2LB-PUR-50/125

Number of fibres/Fibre diameter/Conductor nominal cross section

2x50/125

Outer diameter (d) max. [in]

This article is a discontinued model.

Typical application areas

For heaviest duty applications with 5-7.5 x d
Maximum EMC protection, with high transmission qualities in terms of glass-specific requirements
Almost unlimited resistance to oil
Indoor and outdoor applications
Unsupported travel distances and up to 100 m for gliding applications (horizontal + vertical)
Offshore, ships, storage and retrieval units, machining units/packaging machines, quick handling, semiconductor insertion, refrigeration sector

Guaranteed service life for this series according to guarantee conditions
Further information: chainflex® guarantee

Double strokes*	5 million		7.5 million		10 million
Temperature,	CFLG.LB.PUR	CFLG.LB.CU.PUR	CFLG.LB.PUR	CFLG.LB.CU.PUR	CFLG.LB.PUR	CFLG.LB.CU.PUR
from/to [°C]	R min.[Factor x d]	R min. [Factor x d]	R min.[Factor x d]	R min. [Factor x d]	R min.[Factor x d]	R min. [Factor x d]
-35 / -25	7.5	10	8.5	11	9.5	12
-25 / +70	5	7.5	6	8.5	7	9.5
+70 / +80	7.5	10	8.5	11	9.5	12
