Stepper motors

Filter

Size
Electrical information
Fitting
System
Design

Number of products: 43

drylin® E stepper motor with stranded wire, NEMA 17 with space-saving incremental rotary encoder
  • Protection class motor housing: motor with stranded wires IP40
  • Holding torque: 0.5Nm
  • Nominal current: 1.8A
  • Motor connection: stranded wires

Upon request

Shop now
drylin® E stepper motor with stranded wire, NEMA 24 with space-saving incremental rotary encoder
  • Protection class motor housing: motor with stranded wires IP40
  • Holding torque: 3.5Nm
  • Nominal current: 4.2A
  • Motor connection: stranded wires

Upon request

Shop now
drylin® E stepper motor with stranded wire, NEMA 23 with space-saving incremental rotary encoder
  • Protection class motor housing: motor with stranded wires IP65 (shaft seal IP52)
  • Holding torque: 2.0Nm
  • Nominal current: 4.2A
  • Motor connection: stranded wires

Upon request

Shop now
drylin® E stepper motor with stranded wire, NEMA 34 with space-saving incremental rotary encoder
  • Protection class motor housing: motor with stranded wires IP40
  • Holding torque: 5.9 Nm
  • Nominal current: 6.4 A
  • Motor connection: stranded wires

Upon request

Shop now
drylin® E stepper motor with encoder, waterproof, NEMA 23
  • Installation size: NEMA23/flange installation size 56 mm
  • Protection class motor housing: IP68 (10 m)
  • Holding torque: 1.30 Nm
  • Nominal current: 4.20 A
  • Motor connection: terminal box

from 872.81 USD/Pc.

Shop now
drylin® E stepper motor, NEMA 23XL
  • Installation size: NEMA23XL/flange dimension 60 mm
  • Protection class motor housing: IP65 (Shaft seal IP52)
  • Holding torque: 3.50 Nm
  • Nominal current: 4.20 A
  • Motor connection: Metric connector

from 218.91 USD/Pc.

Shop now
drylin® E lead screw motor with stranded wire and encoder, NEMA 11
  • Installation size: NEMA11/flange installation size 28mm
  • Protection class motor housing: IP40
  • Holding torque: 0.12Nm
  • Nominal current: 1.00A
  • Motor connection: strands and encoder, JST connector

from 173.03 USD/Pc.

Shop now
drylin® E lead screw motor with stranded wire and encoder, NEMA 17
  • Installation size: NEMA17/flange installation size 42mm
  • Protection class motor housing: IP40
  • Holding torque: 0.50Nm
  • Nominal current: 1.80A
  • Moto connection: Strand with JST connector

from 79.14 USD/Pc.

Shop now
drylin® E stepper motor with splash guard, NEMA 23
  • Installation size: NEMA23/flange installation size 56mm
  • Protection class motor housing: IP65
  • Holding torque: 2.0Nm
  • Nominal current: 4.2A
  • integrated shaft seal prevents ingress of water
  • with encoders for safe positioning

Upon request

Shop now
drylin® E stepper motor with stranded wire, NEMA 11
  • Installation size: NEMA11/flange installation size 28mm
  • Protection class motor housing: motor with stranded wires IP40 (shaft seal IP52)
  • Holding torque: 0.12Nm
  • Nominal current: 1.00A
  • Motor connection: strands and encoder, JST connector

Upon request

Shop now
drylin® E stepper motor with stranded wire and encoder, NEMA 11
  • Installation size: NEMA11/flange installation size 28mm
  • Protection class motor housing: motor with stranded wires IP40 (shaft seal IP52)
  • Holding torque: 0.12Nm
  • Nominal current: 1.00A
  • Motor connection: metric connector

Upon request

Shop now
drylin® E lead screw stepper motor with strands, NEMA 23, short type
  • Installation size: NEMA23/flange installation size 56mm
  • Protection class motor housing: IP40
  • Holding torque: 1.00Nm
  • Nominal current: 2.8 A
  • Motor connection: strand with JST connector

from 144.58 USD/Pc.

Shop now
drylin® E stepper motor with connector, NEMA 23
  • Installation size: NEMA23/flange installation size 56mm
  • Protection class motor housing: IP65 (Shaft seal IP52)
  • Holding torque: 2.00Nm
  • Nominal current: 4.20A
  • Motor connection: Metric connector

from 140.10 USD/Pc.

Shop now
drylin® E stepper motor with splash guard, NEMA 17
  • Installation size: NEMA17/flange installation size 42mm
  • Protection class motor housing: IP65
  • Holding torque: 0.5Nm
  • Nominal current: 1.8A
  • integrated shaft seal prevents ingress of water
  • with encoders for safe positioning

Upon request

Shop now
drylin® E stepper motor, waterproof, NEMA 23
  • Installation size: NEMA23/flange installation size 56 mm
  • Protection class motor housing: IP68 (10 m)
  • Holding torque: 1.30 Nm
  • Nominal current: 4.20 A
  • Motor connection: terminal box

from 902.00 USD/Pc.

Shop now
